large supply ASTM A240 410S Stainless Steel sheet thickness 0.3mm-100mm

Place of Origin : China

Brand Name : Seed Steel

Model Number : 410S

Standard : ASTM A240

Thckness : 0.3mm-100mm

Width : 200-3000mm

Type : Plate, Pipe/Tube, Coil

Packaging Details : normally wrapped by plastic film and waterproof paper, and then fastened on wooden pallet or as you

Delivery Time : 15-20 days

Payment Terms : FOB,CIF or others

Supply Ability : 100000pcs

Contact Now

Steel Plate Specification:

Thickness:0.3mm-100mm,

Width:200-3000mm.

Application:

SS 410S is widely used in Petroleum Refining and Petrochemical Processing, Ore Processing, Thermal Processing, Gate valves and Press plates.

410S Stainless Steel Introduction

410S remains soft and ductile even when rapidly cooled from above the critical temperature. This non-hardening characteristic helps prevent cracking when the alloy is exposed to high temperatures or welded. 410S is completely ferritic in the annealed condition. It exhibits adequate corrosion resistance similar to 410 and good oxidation resistance.

410S Stainless Steel Usage

• Petroleum Refining and Petrochemical Processing

Columns

Distillation trays

Heat exchangers

Towers

• Ore Processing

Mining machinery

• Thermal Processing

Annealing boxes

Partitions

Quenching racks

SS 410S Surface Finish：

2B,8K,hairline,NO.4,NO.1,mirror finish

410S Stainless Steel Typical Chemical Requirements (%)

Type	C	Mn	P	S	Si	Cr	Ni	Mo	N
409	≤ 0.030	≤ 1.00	≤ 0.040	≤ 0.020	≤ 1.00	10.5--11.7	0.50	--	0.30
410	0.08--0.15	≤ 1.00	≤ 0.040	≤ 0.030	≤ 1.00	11.5--13.5	0.75	--	--
410S	≤ 0.08	≤ 1.00	≤ 0.040	≤ 0.030	≤ 1.00	11.5--13.5	0.60	--	--

410S Stainless Steel Mechanical Test Requirements

Type	Tensile Strength, min		Yield Strength, min		Elongation in 2 in. or 50mm, min, %	Hardness, max		Cold Bend
Type	ksi	MPa	ksi	Mpa	Elongation in 2 in. or 50mm, min, %	HB	HRB	Cold Bend
409	55	380	25	170	20	179	88	180
410	65	450	30	205	20	217	96	180
410S	60	415	30	205	22	183	89	180
